If the columns are not "range-able" (Col to ColSel) then you might to sort manually each column.Quote:
Originally Posted by Seniorchef
If you want to sort by order of 'City' 'Name' 'Firstname' 'Street' 'Record' then you sort in reverse order to achieve "multi-column" sort.
So first sort by 'Record', then by 'Street' and so on until 'City'.
Thank you, Krool - I'll give it a try.
With the msHFlexGrid I sort with flexSortCustom and the compare event, but unfortunately the VBFlexgrid is very slow in using this method.
Regards
Seniorchef
Yes..Quote:
Originally Posted by Seniorchef
MergeSort is used for automatic sorting as it is fast and stable.
BubbleSort is used for custom sorting as row1/row2 for text matrix must be meaningful in the 'Compare' event.
If a faster replacement for the custom sorting is possible I am eager to read about.
Hello friend Krool, how can I do? to be able to have cells with progressBar in the VbFlexgrid.
Please I need your support.
Attachment 182323
Dear Krool I found a problem in the grid, this happens when you add the grid in a form, and you put it in properties:
FixedRos = 1
rows = 2
fixedcol = 0
You close the form and open the form again and Vb 6.0 hangs (does not respond).
attached image
Attachment 182325
I can't replicate. Please review.Quote:
Originally Posted by lizano diaz
Hello, Krool!
Sorry for my late answer, but I wanted to test the issue before I report.
I don't know how, but the custom sort of the msHFlexgrid is way faster than the custom sort of the vbFlexGrid - it's about the factor 30 on a single column sort. So they have either a different way to sort customly or a faster algorithm.
Just a thought. I would love to replace the msHFlexGrid with the VBFlexGrid, but the custom sort is a real killjoy.
Thanks for your efforts anyway. I really appreciate your work very well.
Regards
Seniorchef
How many records are you talking about?
How do you initially fill the grid?
If it's from a query then you could add sorting to the query.
If it's from some other dataset then you could do a sort on your data first, before assigning it to the grid.
Hello, Arnoutdv!
In this test it's 600 records - it becomes worse with more records (obviously).
On my pc it took 6 sec with vbFlexGrid and 0.2 sec with msHFlexgrid.
The grid is filled already, and I sort per mouseclick on columnheader. The data is unbound.
Greetings
Seniorchef
6 sec with 600 records?Quote:
Originally Posted by Seniorchef
Can you share the code? (Maybe there is a late-bound inefficiency)
Also, what kind of custom sort you are doing?
For instance VbFlexGrid has an enum for date sort (thus fast as not custom) maybe I can add an enum for your use-case.
I also check if I can change the BubbleSort to a GnomeSort for custom sorting. (It should perform a little bit better) Lets see..
Hello, Krool!
I know - 6 seconds is a long time compared to 0.2 seconds.
Even if it is a slow pc and there is a lot of overhead while sorting, this is valid for both grids. The code I use to test is identical (except the compare-event for each grid has one different argument).
I'm doing the custom sort to achive multicolumn sort, ascending, descending in flexible order (see my post #601).
I know about the built-in sort abilities, but they cannot sort as flexible as I need to. On the other hand, the custom sort works really fine and is exactly what I need, but it is slow.
It is the BubbleSortIter() Sub. I'm not experienced in sorting algorithms, but maybe it should be replaced by a faster one.
If we knew the way the msHflexGrid handles this we had the solution, I'm sure.
Maybe there is a user who can tell us.
Greetings
Seniorchef
Bubblesort is stable, but very slow, sorting method
Mergesort is also stable and much faster.
@Seniorchef, have you tried it compiled or only from within the IDE?
Mergesort implementation:
http://www.vb-helper.com/howto_mergesort.html
I use MergeSort already.Quote:
Originally Posted by Arnoutdv
However, for custom sort (firing Compare event where Text Matrix of row1/row2 are valid) the Merge Sort is not possible, thus BubbleSort for that.
If there is a working/valid alternative possible please let me know.
Hello, Arnoutdv!
Honestly, I tested it in the IDE. But after your post I compiled it and - the result stays the same.
Btw, thank you for the link - MergeSort is already in the VBFlexGrid Sort routine, and, if possible and his time permits, it should be adapted by Krool for the custom sort.
Either way, I don't want to rush the issue, and maybe he'll find another way to speed up the routine.
Regards
Seniorchef
Again, it's logical NOT POSSIBLE to use merge sort for custom sort.Quote:
Originally Posted by Seniorchef
And that's because you can not just pass the 2 values to compare, but because the sorted items can also be things like the backcolor of the cell or it's custom data property?
Well yes... The MS(H)FlexGrid also passes row1/row2.Quote:
Originally Posted by Arnoutdv
If I would pass Text1/Text2 to Compare event the MergeSort would work.
Maybe an additional event CompareValues and an additional sort method, CustomValue
Please krool could you support me with the request of: # 604
Please thank you very much
Hello and good morning.
Ok, this morning I woke up and I think I got a solution for my problem. If it works, there will be no need for the custom sort event cause I'll enhance the regular sort routine. I'll try it and tell the results.
Greetings
Seniorchef
I tested the following:
Code:' VBFlexGrid.ctl
Private FlexSortNone, FlexSortGenericAscending, FlexSortGenericDescending, FlexSortNumericAscending, FlexSortNumericDescending, FlexSortStringNoCaseAscending, FlexSortStringNoCaseDescending, FlexSortStringAscending, FlexSortStringDescending, FlexSortCustom, FlexSortCustomValue, FlexSortUseColSort, FlexSortCurrencyAscending, FlexSortCurrencyDescending, FlexSortDateAscending, FlexSortDateDescending
Public Enum FlexSortConstants
FlexSortNone = 0
FlexSortGenericAscending = 1
FlexSortGenericDescending = 2
FlexSortNumericAscending = 3
FlexSortNumericDescending = 4
FlexSortStringNoCaseAscending = 5
FlexSortStringNoCaseDescending = 6
FlexSortStringAscending = 7
FlexSortStringDescending = 8
FlexSortCustom = 9
FlexSortUseColSort = 10
FlexSortCurrencyAscending = 11
FlexSortCurrencyDescending = 12
FlexSortDateAscending = 13
FlexSortDateDescending = 14
FlexSortCustomValue = 15
End Enum
Public Event CompareValue(Value1 As String, Value2 As String, ByRef Cmp As Long)
Private Sub InplaceMergeSort(ByVal Left As Long, ByVal Middle As Long, ByVal Right As Long, ByVal Col As Long, ByRef Data() As TCOLS, ByVal Sort As FlexSortConstants)
'
'
Select Case Sort
Case FlexSortCustomValue
RaiseEvent CompareValue(Data(i).Cols(Col).Text, Temp(j).Cols(Col).Text, Cmp)
It's running in full speed on the sample VBFlexGridDemo with 600 rows :)Code:' MainForm
Private Sub VBFlexGrid1_Compare(ByVal Row1 As Long, ByVal Row2 As Long, ByVal Col As Long, Cmp As Long)
Dim dValue1 As Double, dValue2 As Double
dValue1 = CDbl(VBFlexGrid1.TextMatrix(Row1, Col))
dValue2 = CDbl(VBFlexGrid1.TextMatrix(Row2, Col))
If dValue1 > dValue2 Then Cmp = 1 Else Cmp = -1
End Sub
Private Sub VBFlexGrid1_CompareValue(Value1 As String, Value2 As String, Cmp As Long)
If CDbl(Value1) > CDbl(Value2) Then Cmp = 1 Else Cmp = -1
End Sub
Private Sub Command17_Click()
Dim Row1 As Long, Row2 As Long
Dim Col1 As Long, Col2 As Long
With VBFlexGrid1
.GetSelRange Row1, Col1, Row2, Col2
.RowID(.Row) = 1 ' Temporary identification
.Sort = FlexSortCustomValue
'.Sort = VBA.Choose(Combo2.ListIndex + 1, FlexSortGenericAscending, FlexSortNumericAscending, FlexSortStringNoCaseAscending, FlexSortStringAscending, FlexSortCurrencyAscending, FlexSortDateAscending)
.Row = .RowIndex(1)
.RowID(.RowIndex(1)) = 0 ' Remove temporary identification
.CellEnsureVisible
If Row1 <> Row2 Then .RowSel = IIf(Row1 < .Row, Row1, Row2)
If Col1 <> Col2 Then .ColSel = IIf(Col1 < .Col, Col1, Col2)
End With
End Sub
I first sort Column 1 with the Dates Descending with SortType "String"
Then a numeric value column with Sort Asc, which has a hardcoded .Sort = FlexSortCustumValue
@ Arnoutdv,
good idea with a second custom sort which can be based on the merge sort.
However, why CustomValue/CompareValue (Value1/Value2) ? I would like CustomText/CompareText (Text1/Text2) more..
*Text instead of *Value is indeed better, much more obvious what is going on.
Even VSflexGrid admits that it's of magnitude slower the Compare event.
http://helpcentral.componentone.com/...mpareevent.htm
So I'm wondering what the heck msHFlexGrid is doing..
Update released.
Included the FlexSortCustomText enum with corresponding CompareText event.Quote:
Originally Posted by Arnoutdv
I found a way to "improve" the bubble sort.
Let's take the demo example (rows increased from 150 to 600)
The original version takes 11 seconds in the IDE. The new modified version takes 3.5 seconds.
The green part is old and commented out. The blue part is added.
The red part is the time safer. The ReDim needs to be done only 1 time.
What you think ?Code:Private Sub BubbleSortIter(ByVal First As Long, ByVal Last As Long, ByVal Col As Long, ByRef Data() As TCOLS)
Dim Swap As TCOLS, Cmp As Long
ReDim Swap.Cols(0 To (PropCols - 1)) As TCELL
Dim i As Long, j As Long, iCol As Long
Do While Last > First
i = First
For j = First To Last - 1
Cmp = 0
RaiseEvent Compare(j, j + 1, Col, Cmp)
If Cmp > 0 Then
' LSet Swap = Data(j + 1)
' LSet Data(j + 1) = Data(j)
' LSet Data(j) = Swap
LSet Swap.RowInfo = Data(j + 1).RowInfo
LSet Data(j + 1).RowInfo = Data(j).RowInfo
LSet Data(j).RowInfo = Swap.RowInfo
For iCol = 0 To (PropCols - 1)
LSet Swap.Cols(iCol) = Data(j + 1).Cols(iCol)
LSet Data(j + 1).Cols(iCol) = Data(j).Cols(iCol)
LSet Data(j).Cols(iCol) = Swap.Cols(iCol)
Next iCol
i = j
End If
Next j
Last = i
Loop
End Sub
EDIT: (revised version, to be released soon)
Code:Private Sub BubbleSortIter(ByVal First As Long, ByVal Last As Long, ByVal Col As Long, ByRef Data() As TCOLS)
Dim SwapRowInfo As TROWINFO, SwapCell As TCELL, Cmp As Long
Dim i As Long, j As Long, iCol As Long
Do While Last > First
i = First
For j = First To Last - 1
Cmp = 0
RaiseEvent Compare(j, j + 1, Col, Cmp)
If Cmp > 0 Then
LSet SwapRowInfo = Data(j + 1).RowInfo
LSet Data(j + 1).RowInfo = Data(j).RowInfo
LSet Data(j).RowInfo = SwapRowInfo
For iCol = 0 To (PropCols - 1)
LSet SwapCell = Data(j + 1).Cols(iCol)
LSet Data(j + 1).Cols(iCol) = Data(j).Cols(iCol)
LSet Data(j).Cols(iCol) = SwapCell
Next iCol
i = j
End If
Next j
Last = i
Loop
End Sub
Code:Private Sub InplaceMergeSort(ByVal Left As Long, ByVal Middle As Long, ByVal Right As Long, ByVal Col As Long, ByRef Data() As TCOLS, ByVal Sort As FlexSortConstants)
Dim Temp() As TCOLS, Cmp As Long, Dst As Long
Dim i As Long, j As Long, iCol As Long
Dim Dbl1 As Double, Dbl2 As Double
ReDim Temp(Middle - Left) As TCOLS
j = 0
For i = Left To Middle
LSet Temp(j) = Data(i)
j = j + 1
Next i
j = 0
Dst = Left
Do While i <= Right And j <= UBound(Temp)
Cmp = 0
Select Case Sort
Case FlexSortGenericAscending, FlexSortGenericDescending
If Not IsNumeric(Data(i).Cols(Col).Text) Or Not IsNumeric(Temp(j).Cols(Col).Text) Then
If Data(i).Cols(Col).Text < Temp(j).Cols(Col).Text Then
Cmp = -1
ElseIf Data(i).Cols(Col).Text > Temp(j).Cols(Col).Text Then
Cmp = 1
End If
Else
Dbl1 = Empty: Dbl2 = Empty
On Error Resume Next
Dbl1 = CDbl(Data(i).Cols(Col).Text)
Dbl2 = CDbl(Temp(j).Cols(Col).Text)
On Error GoTo 0
Cmp = Sgn(Dbl1 - Dbl2)
End If
If Sort = FlexSortGenericDescending Then Cmp = -Cmp
Case FlexSortNumericAscending, FlexSortNumericDescending
Dbl1 = Empty: Dbl2 = Empty
On Error Resume Next
Dbl1 = CDbl(Data(i).Cols(Col).Text)
Dbl2 = CDbl(Temp(j).Cols(Col).Text)
On Error GoTo 0
Cmp = Sgn(Dbl1 - Dbl2)
If Sort = FlexSortNumericDescending Then Cmp = -Cmp
Case FlexSortStringNoCaseAscending, FlexSortStringNoCaseDescending
Cmp = lstrcmpi(StrPtr(Data(i).Cols(Col).Text), StrPtr(Temp(j).Cols(Col).Text))
If Sort = FlexSortStringNoCaseDescending Then Cmp = -Cmp
Case FlexSortStringAscending, FlexSortStringDescending
Cmp = lstrcmp(StrPtr(Data(i).Cols(Col).Text), StrPtr(Temp(j).Cols(Col).Text))
If Sort = FlexSortStringDescending Then Cmp = -Cmp
Case FlexSortCurrencyAscending, FlexSortCurrencyDescending
Dim Cur1 As Currency, Cur2 As Currency
Cur1 = Empty: Cur2 = Empty
On Error Resume Next
Cur1 = CCur(Data(i).Cols(Col).Text)
Cur2 = CCur(Temp(j).Cols(Col).Text)
On Error GoTo 0
Cmp = Sgn(Cur1 - Cur2)
If Sort = FlexSortCurrencyDescending Then Cmp = -Cmp
Case FlexSortDateAscending, FlexSortDateDescending
Dim Date1 As Date, Date2 As Date
Date1 = Empty: Date2 = Empty
On Error Resume Next
Date1 = CDate(Data(i).Cols(Col).Text)
Date2 = CDate(Temp(j).Cols(Col).Text)
On Error GoTo 0
Cmp = Sgn(Date1 - Date2)
If Sort = FlexSortDateDescending Then Cmp = -Cmp
Case FlexSortCustomText
RaiseEvent CompareText(Data(i).Cols(Col).Text, Temp(j).Cols(Col).Text, Col, Cmp)
End Select
If Cmp < 0 Then
LSet Data(Dst).RowInfo = Data(i).RowInfo
For iCol = 0 To (PropCols - 1)
LSet Data(Dst).Cols(iCol) = Data(i).Cols(iCol)
Next iCol
i = i + 1
Else
LSet Data(Dst).RowInfo = Temp(j).RowInfo
For iCol = 0 To (PropCols - 1)
LSet Data(Dst).Cols(iCol) = Temp(j).Cols(iCol)
Next iCol
j = j + 1
End If
Dst = Dst + 1
Loop
Do While j <= UBound(Temp)
LSet Data(Dst).RowInfo = Temp(j).RowInfo
For iCol = 0 To (PropCols - 1)
LSet Data(Dst).Cols(iCol) = Temp(j).Cols(iCol)
Next iCol
Dst = Dst + 1
j = j + 1
Loop
End Sub
Updated BubbleSortIter/InplaceMergeSort for better performance on UDT assignment.
Also posted in the [VB6] variant thread (just saw this one):
Thank you!Quote:
Does this work in Excel? Does anyone have an example of how to get this up and running in an Excel form?
I added a reference to the ocx and tlb but cannot see a control to add to the palette in the form builder. What are the steps please?
Question..
For a potential .ColSortArrow property should I use a fixed image for up/down arrow or just draw with same cell font as unicode char U+25B2 (▲) and U+25BC (▼) ?
How about using the Unicode characters unless they are not present in whatever font you are using in which case you switch to a fixed image?Quote:
Originally Posted by Krool
Using Unicode character is easier at it scales according to size/dpi etc.Quote:
Originally Posted by MountainMan
So unless a Wingdings font is used this works great. And it works back to Win XP, no? (Need to test)
Also the fore color works in sync
Update released.
Included the ColSortArrow property. I decided to just draw a triangle to be independent of fonts. Also it ensures to work then in Windows XP.
However, the triangle is calculated upon TEXTMETRICS so it scales accordingly..
The internal GetTextSize and GetLabelInfo considers the triangle accordingly.
The triangle is only drawn on the first fixed row.
Attachment 182458
This code will conveniently remove (quickly) all sort arrows on each column.
Code:VBFlexGrid1.ColSortArrow(-1) = FlexSortArrowNone
Currently the sort arrow is drawn right or left aligned depending on the text alignment. When text is left or centered the sort arrow is right, else left.
I may include another ColSortArrowAlignment property which could be set to 0 - NoControl, 1 - Right and 2 - Left...
Included the ColSortArrowColor property.
The default value on each column is -1. This means the applied text color of that cell is used as color for the sort arrow.
This property allows to specify an explicit color.
Attachment 182473
Some finetuning for ColSortArrowColor property.
When set to -1 the get property will not return -1 anymore and just fallback to the color that will be used then for drawing.
This is then in line with the other color properties and the fallbacks accordingly.
Update released.
Renamed enum FlexColSortArrowUp to FlexColSortArrowAscending and FlexColSortArrowDown to FlexColSortArrowDescending.
This is then easier to use (not to think about if up is ascending and down is descending) and also in harmony with the general sort enums.
Included the RowSortArrows property. The default value is 0 for the first fixed row. This property may be modified to display the sort arrows on a different fixed row.
Introduced now a SortArrowColor property which defaults to vbGrayText.
It's in practise easier to have a global color property which can be set at design time. Because ColSortArrowColor needs to be set by code and when a grid erases (e.g. Rows = 0) the values are lost.
So, ColSortArrowColor still exists now and when set to -1 it fallbacks to the global SortArrowColor.
This is much cleaner and more predictable than the previous two cases fallback between cell forecolor and forecolor fixed.
Dear krool,
As always, my thanks in TONS to you for your free contribution to this world society. And, special thanks for the sort arrow with color, default color, alignment, etc. I was using my own simple arrow earlier. Your work with so many options makes it all so easy now. I have not explored them fully yet. Will do soon but lot many thanks in advance.
Well, is there a page which explains the meaning of all (or the most important) properties of your VBFlexGrid control? For instance, intuitively, I thought .colsvisible will just give me the number of columns which are not hidden in a grid (i.e. total number of columns minus the columns with .colhidden = true) but it was not so. Object browser told me that .colsvisible "Returns the total number of columns or rows visible in the flex grid."
To understand the above statement from the Object Browser better, I just experimented with a sample 10*10 flex grid. I realised that even if I hide some columns (say 1, 2 and 3) and reduce the width of the grid to show only 2 columns (i.e. only column 0 and column 4), then also .colsvisible will return 5 and not 2. Is it so by design? Just a clarification. Thats all.
.rowsvisible also behaves similarly with a similar experiment as above. So, just wanted to clarify whether .colsvisible and .rowsvisible are designed to report values in the above manner only.
I have some clarifications regarding how and where to avail ComboListCount, ComboListIndex, ComboList, etc. Will ask them in a separate message.
Thanks again.
Kind regards.
Dear krool,
This is in continuation of my last message (in which I have requested your clarification on .colsvisible and .rowsvisible).
And, reg. the various ComboList values, I am sorry that I am not that very clear in my understanding of them.
So, via the following cases, I am trying to understand them in the right way from you. So, kindly please help.
Case 1)
In your VBFlexGrid demo, in UserEditingForm, I have the following lines at the end of the Form_Load event.
The above print '0', '0', 'Z' and 'Arnold|Bob|Charlie|David|Elena|Felix|Greg|Hanna|Ivan|Jacob'Code:Debug.Print VBFlexGrid1.ComboListCount
Debug.Print VBFlexGrid1.ComboListIndex
Debug.Print VBFlexGrid1.ComboList(10) & "Z"
Debug.Print VBFlexGrid1.ColComboItems(10)
a) Why '0' got printed for .ComboListCount? Why .ComboList(10) prints empty string?
b) Even if I make the rows count as 2 for VBFlexGrid1 and select 'Ivan' (instead of the default Arnold) in both the 10th and 11th columns, then also .ComboListIndex is printed as '0' only. Why?
c) Perhaps .ComboList, .ComboListCount and .ComboListIndex carry meaning only when they are used in specific events like VBFlexGrid1_EnterEdit(), VBFlexGrid1_LeaveEdit(), etc.? If so, in which all events they carry meaning? Please let me know.
Case 2)
At the end of the VBFlexGrid1_EnterEdit() event, I have the following lines.
And, when I double click a cell in the 10th column where 'Charlie' is present, what get printed are:Code:Debug.Print VBFlexGrid1.ComboListCount
Debug.Print VBFlexGrid1.ComboListIndex
'''''Debug.Print VBFlexGrid1.ComboList(10) & "Z"
Debug.Print VBFlexGrid1.ColComboItems(10)
'10', '2' and 'Arnold|Bob|Charlie|David|Elena|Felix|Greg|Hanna|Ivan|Jacob'
I had to comment out the 3rd line above because it caused a run time error (Invalid procedure call or argument).
a) Why the 3rd line caused an error? Please educate me. Is it that it cannot or should not be used in certain events?
b) Where then should (or where all I can) use that line so that it will show some output?
c) What actually is .ComboList(10) supposed to show? Is it supposed to show the same output of ColComboItems(10) but without the '|' and all the 10 names displayed one after the other, in 10 lines?
Case 3)
At the end of the VBFlexGrid1_LeaveEdit() event, I have the following lines.
And, when I double click a cell in the 10th column where Charlie is present and select Charlie itself again, what get printed are:Code:Debug.Print VBFlexGrid1.ComboListCount
Debug.Print VBFlexGrid1.ComboListIndex
'Debug.Print VBFlexGrid1.ComboList(10) & "A"
Debug.Print VBFlexGrid1.ColComboItems(10)
VBFlexGrid1.ComboListIndex = 9
Debug.Print "yes"; VBFlexGrid1.ComboListIndex
'10', '2', 'Arnold|Bob|Charlie|David|Elena|Felix|Greg|Hanna|Ivan|Jacob' and 'yes 9'
a) I had to keep the 3rd line commented out here also since it caused the same run time error (Invalid procedure call or argument).
b) Though I changed the .ComboListIndex to 9, the selection remained at 'Charlie' only.
c) So, where and how should I use .ComboListIndex so that I can "programmatically" change/select the ComboList item in any cell in the 10th column (ComboDropDown) without having to manually double click a cell and select a particular item in the list.
Thanks a TON once again for your contribution to the world society.
Kind regards.
Dear krool,
One more thing. Can there be a 'ExtendThisCol = <Col No.>' property too?
For instance, say my design requires me to have a chunk of text in the 1st column of a 3-column grid and fixed width values in the 2 and 3rd columns.
Then, I would not like to extend my last column. I would like to extend my first column only. So, in such cases, 'ExtendThisCol' property will be very helpful I thought. Of course, I can do this via code itself. In fact, I was already achieving 'EntendLastCol' through my own code only. But, a properly like 'EntendLastCol' introduced by you is easier and thus very helpful. That's why my suggestion for ExtendThisCol too.
Kind regards.
ColComboItems is similar to the ComboItems property, except it applies to entire columns. This is often more convenient that using the ComboItems property because you may set the ColComboItems property once for each column, whereas the ComboItems property normally needs to be set in the BeforeEdit event.Quote:
Originally Posted by softv
ComboListCount, ComboListIndex and ComboList(x) are properties to extract info from a once defined ColComboItems/ComboItems.
So, ComboList(x) is to extract x entry for the current column. X is not the column, that's why you had an error.
Dear krool,
As in the case of 'sort', is it possible to show a chevron (inside a square preferably) by the side of the cells of the column whose .ColComboMode is set to FlexComboModeDropDown (or) FlexComboModeEditable? Because, this way, a user will readily know that there is a ComboList existing in the cells of that column.
If the above is not possible, then what is the easiest way to indicate to the user by text that there is a ComboList existing in those cells? Anyway, since indication via picture is the best way, what is the easiest way to make a chevron get displayed by the side of all such ComboList cells? Draw a picture using ".Cell(FlexCellPicture)"? If so, what would be the best way to draw the chevron pictures so that they appear correctly in all resolutions, etc.? And, will it be possible to act upon click events on those chevron pictures? If not, capturing mouse click events on X,Y coordinates of those chevrons is the only way? Well, any suggestions are welcome. Thanks in advance.
Kind regards.
ComboList(x). Thanks a lot, krool. Understood. I think I have understood difference between ColComboItems and ComboItems too. If there are doubts, I shall write again.Quote:
Originally Posted by Krool
As of now, can you kindly let me know whether it is possible to programmatically change/select the ComboList item in any cell of a column whose ColComboMode is set to FlexComboModeDropDown (or FlexComboModeEditable)? If so, can you kindly give me a code sample please?
Kind regards.
Use ComboListIndex to change the selected list item.Quote:
Originally Posted by softv
I had already tried it but did not succeed. But, after seeing your instruction, I tried again and achieved it. Thanks a TON.Quote:
Originally Posted by Krool
However, I request you to tell me whether there is a better way to achieve it than the way I have adopted below. The code I used (in a button click) was:
The above worked like a charm, to programmatically select a list item. Thanks a TON once again.Code:With VBFlexGrid1
.Row = 2
.Col = 10
.StartEdit
.ComboListIndex = 5
'''''.CommitEdit
End With
SendKeys vbLf
But, I feel there must be a better alternative to 'SendKeys vbLf'.
That's why I tried VBFlexGrid1.CommitEdit, but it did not change the ComboListIndex to 5. The dropdown just closed. Kindly suggest me an alternative to 'SendKeys vbLf', if any. Thanks in advance.
Kind regards.
The .ComboListIndex = 5 works as it should. What do you want to achieve, to just avoid user selection and commit list entry 5 ?Quote:
Originally Posted by softv
The below code will do it without SendKeys vbLf...
Code:VBFlexGrid1.EditText = VBFlexGrid1.ComboList(5)
VBFlexGrid1.CommitEdit
Perfect, Krool. Thank you so much. :)Quote:
Originally Posted by Krool
Kind regards.
Dear krool,
is it possible to freeze rows (one or more) from the bottom rows of a grid? If so, what should I do? Thanks.
As of now, just to freeze the very last row of the grid is enough for me so that when user scrolls up and down, the last row is always visible.
Kind regards.
Not possible. Even Excel doesn't allow it.Quote:
Originally Posted by softv
What you want actually? Maybe there is an alternative..
Oh okay, krool. Understood.Quote:
Originally Posted by Krool
I just wanted to show the number of records (at any point of time in the grid) in the last row of the grid itself.
Right now, I am using an alternative only. I am showing the records count in a separate control placed below the grid. If there is a better alternative, kindly let me know.
I just felt that showing the records count (which will be just .rows-1, in my grid's case) inside the grid itself in a frozen last row will be ideal. That's all.
Kind regards.
There is no "picture click" event.Quote:
Originally Posted by softv
What's the use-case you want to achieve?
Dear krool,Quote:
Originally Posted by Krool
As written earlier, the use-case is for the user to readily know that a drop down list is present in the cells of a particular column. Obviously, I cannot have column names as DropDown Combo, etc. So, there should be some pictorial indication somewhere to the user so that he knows immediately on seeing the grid that there is a drop down available in the cells of a particular column. Any kind of suggestions towards achieving this (in whatever manners possible) is welcome. Thanks in advance.
Kind regards.
Update released.
The workaround with .ComboButtonValue to 'FlexComboButtonValueDisabled' is not needed anymore. There is a new event now 'ComboBeforeDropDown'.Quote:
Originally Posted by TheLeePiper
So you can achieve the wanted behavior now easily by following code:
Code:Private Sub VBFlexGrid1_ComboBeforeDropDown(ByVal Reason As FlexComboDropDownReasonConstants, Cancel As Boolean)
If Reason = FlexComboDropDownReasonInitialize Then Cancel = True
End Sub
That's an interesting question. So, a visual cue that a dropdown will appear when attempting to edit.Quote:
Originally Posted by softv
The not disturbing approach would be not to always show such a "chevron" but only when that cell is selected. Using the RowColChange event.
However, using a picture with right align and no overlap would be the easiest and dynamically set/clear upon RowColChange.
Difficult part is to create such a dynamic scaled picture at run-time. (Using DrawFrameControl etc.)
I have suspended work on the VBFlexGrid.NET for now and have pivoted to migrating the VBFlexGrid to a native ActiveX control written with C++ and ATL.Quote:
Originally Posted by Krool
A native ActiveX control should work better with traditional ActiveX consumers like VB6, there being no interop or .NET Framework issues, while providing 64-bit compatibility for modern Office.
RD
Update released.
Included the ColSortArrowAlignment property, which is either left or right (default). This way it's explicit and cleaner.
Also, there was a bug in the DoubleBuffer property when changing RightToLeft/RightToLeftLayout at run-time.
Attachment 182665
The DoubleBufferDC is initially correctly setup thanks to CreateCompatibleDC. However, when the layout changes to RTL then the DoubleBufferDC was not updated.
Now, it's set via SetLayout API to LAYOUT_RTL or 0 on WM_STYLECHANGED to fix this.
I'm having the idea of including a 'ComboModeCalendar' which has as drop-down client a SysMonthCal32.
However, parsing the date to the MonthView is done with IsDate() and CDate(). If date is invalid it has then today's date as current selection in the drop-down window.
Problem is how to put back the date into text?
I'm thinking of a ComboFormat property which can be set. If empty it just passes Text = Date. Else uses Format$().
Or is it too much and discard the idea? The vsFlexGrid also does not have it.
Though I could find useful use for such a mode..
I suggest a public enum and Format$ with an optional separator string "-" or "/":Quote:
Originally Posted by Krool
Code:Public Enum DateFormatEnum
YMD = 0 'YYYY-MM-DD
MDY = 1 'MM-DD-YYYY
DMY = 2 'DD-MM-YYYY
System = 3
End Enum
Thanks for feedback. I may consider just to cast .EditText = Date from the calendar. (System format then)Quote:
Originally Posted by DaveDavis
The app can use the ValidateEdit event to modify .EditText with a Format of choice before the commit to the cell is done.
Update released.
Included enum FlexComboModeCalendar.
Attachment 182716
To ensure unique format you may put following in ValidateEdit event.
Beside ComboCalendarValue, there is also ComboCalendarMinDate/ComboCalendarMaxDate available.Code:If Cancel = False Then
' Ensure unique date format before commit. (override possible custom format of the text box)
VBFlexGrid1.EditText = VBFlexGrid1.ComboCalendarValue
End If
