[RESOLVED] xpath expression help

[coolcurrent4u]

for each "<entry>" in this xml, i need to get the "title" and the first thumbnail image. that is the first image in the media:group

<?xml version='1.0' encoding='UTF-8'?>
<feed xmlns='http://www.w3.org/2005/Atom' xmlns:media='http://search.yahoo.com/mrss/'>
<entry>
<title>Progression! 9 more pounds to goo!</title>
<media:group>
<media:thumbnail url='http://i.ytimg.com/vi/7MTjYXt3rLQ/default.jpg'/>
<media:thumbnail url='http://i.ytimg.com/vi/7MTjYXt3rLQ/mqdefault.jpg'/>
<media:thumbnail url='http://i.ytimg.com/vi/7MTjYXt3rLQ/hqdefault.jpg'/>
<media:thumbnail url='http://i.ytimg.com/vi/7MTjYXt3rLQ/1.jpg'/>
<media:thumbnail url='http://i.ytimg.com/vi/7MTjYXt3rLQ/2.jpg'/>
<media:thumbnail url='http://i.ytimg.com/vi/7MTjYXt3rLQ/3.jpg'/>
</media:group>
</entry>
<entry>
<title>Plank Variations Workout with Max Wettstein</title>
<media:group>
<media:thumbnail url='http://i.ytimg.com/vi/O1Nd8lZFGpc/default.jpg'/>
<media:thumbnail url='http://i.ytimg.com/vi/O1Nd8lZFGpc/mqdefault.jpg'/>
<media:thumbnail url='http://i.ytimg.com/vi/O1Nd8lZFGpc/hqdefault.jpg'/>
<media:thumbnail url='http://i.ytimg.com/vi/O1Nd8lZFGpc/1.jpg'/>
<media:thumbnail url='http://i.ytimg.com/vi/O1Nd8lZFGpc/2.jpg'/>
<media:thumbnail url='http://i.ytimg.com/vi/O1Nd8lZFGpc/3.jpg'/>
</media:group>
</entry>
</feed>

this is my code

Dim xmlDoc As MSXML2.DOMDocument30
    Dim xmlEntryNode As MSXML2.IXMLDOMNode
    Dim xmlEntryNodes As IXMLDOMNodeList
    Dim xmlC1Nodes As IXMLDOMNodeList
    Dim ns As String
    Set xmlDoc = New DOMDocument30
    ns = txtNS.Text
    xmlDoc.setProperty "SelectionLanguage", "XPath"
    xmlDoc.setProperty "SelectionNamespaces", ns

    If xmlDoc.loadXML(txtXml.Text) = False Then
        appendText "xml document load failed"
        Exit Sub
    End If
    Set xmlEntryNodes = xmlDoc.documentElement.selectNodes(/x:feed/x:entry)
    Dim i As Integer
    For i = 0 To xmlEntryNodes.length - 1
        Set xmlEntryNode = xmlEntryNodes(i)
        appendText xmlEntryNode.Text
        Set xmlC1Nodes = xmlDoc.selectNodes(//media:group/media:thumbnail[1]/@url)
        If xmlC1Nodes.length > 0 Then
            Dim j As Integer
            For j = 0 To xmlC1Nodes.length - 1
                appendText xmlC1Nodes(j).Text
            Next
        End If
    Next

    Exit Sub

and here is my output


Progression! 9 more pounds to goo!
http://i.ytimg.com/vi/7MTjYXt3rLQ/default.jpg
http://i.ytimg.com/vi/O1Nd8lZFGpc/default.jpg
Plank Variations Workout with Max Wettstein
http://i.ytimg.com/vi/7MTjYXt3rLQ/default.jpg
http://i.ytimg.com/vi/O1Nd8lZFGpc/default.jpg

can anyone pls help me adjust to make it return only one image for each "<entry>"

[Max187Boucher]

looks like its in your last for j = ... next loop

replace

Dim j As Integer
  For j = 0 To xmlC1Nodes.length - 1
    appendText xmlC1Nodes(j).Text
  Next

to

appendtext xmlC1Nodes(0).Text

if that one is wrong change 0 to 1

i have not tested any code

[coolcurrent4u]

i have tried that, it gives the same image for both entries

Progression! 9 more pounds to goo!
http://i.ytimg.com/vi/O1Nd8lZFGpc/default.jpg
Plank Variations Workout with Max Wettstein
http://i.ytimg.com/vi/O1Nd8lZFGpc/default.jpg

[Max187Boucher]

ok maybe this would do it not tested again

        Dim i As Integer
          Set xmlC1Nodes = xmlDoc.selectNodes("//media:group/media:thumbnail[1]/@url")
            For i = 0 To xmlEntryNodes.length - 1
              Set xmlEntryNode = xmlEntryNodes(i)
              appendText xmlEntryNode.Text
              appendText xmlC1Nodes(i).Text
          Next

[Doogle]

There's something not quite right here:

1. The Set statements

Set xmlEntryNodes = xmlDoc.documentElement.selectNodes(/x:feed/x:entry)
Set xmlC1Nodes = xmlDoc.selectNodes(//media:group/media:thumbnail[1]/@url)

cause a compile error "Expected Expression"
I think you need some quotes round the expression in brackets

2. You're saying that you're getting output but there are 6 <media:thumbnail> elements in each group but you're only reporting 2

Did you post the actual code and data ?

[coolcurrent4u]

yes that was a typo error

[Doogle]

What other typos are there?

It doesn't seem to like ("/x:feed/x:entry") either.

Wouldn't it be easier to copy and paste the actual code that's running ? At least then we have a fighting chance.

BTW what does the 'appendText' routine do ?

[Max187Boucher]

From what he posted looks like its adds text & vbnewline to textbox/string or adds item to a listbox

I agree to posting actual code not just a "kind of" like code example

[coolcurrent4u]

Hello, here is the attached project


RssXpath.zip

[Doogle]

Your problem is that you're changing xmlEntryNodes within a loop controled by xmlEntryNodes.Length making the For / Next loop iterate too many times. EDIT: In fact by the second iteration, it's not the same object that you started with.
Modified code:

Private Sub cmd1_Click()
    On Error GoTo ErrorHandler:
    txtOut.Text = ""
    'Prepare a regular expression object
    Dim xmlDoc As MSXML2.DOMDocument30
    Dim xmlEntryNode As MSXML2.IXMLDOMNode
    Dim xmlEntryNodes As IXMLDOMNodeList
    Dim xmlEntryNodes1 As IXMLDOMNodeList
    Dim xmlC1Nodes As IXMLDOMNodeList
    Dim ns As String
    Set xmlDoc = New DOMDocument30
    ns = txtNS.Text
    xmlDoc.setProperty "SelectionLanguage", "XPath"
    xmlDoc.setProperty "SelectionNamespaces", ns

    If xmlDoc.loadXML(txtXml.Text) = False Then
        appendText "xml document load failed"
        Exit Sub
    End If
    Set xmlEntryNodes = xmlDoc.documentElement.selectNodes(txtXP.Text)
    appendText "ENodes = ", xmlEntryNodes.length
    Dim i As Integer
    For i = 0 To (xmlEntryNodes.length) - 1
        Set xmlEntryNode = xmlEntryNodes(i)
        If xmlDoc.loadXML(xmlEntryNode.xml) = True Then
            Set xmlEntryNodes1 = xmlDoc.documentElement.selectNodes(txtXP2.Text)
            'Set xmlEntryNodes = xmlEntryNode.selectNodes(txtXP2.Text)
            'If xmlC1Nodes.length > 0 Then
            appendText xmlEntryNodes1(0).Text

            'End If


            '            Dim j As Integer
            '            For j = 0 To xmlC1Nodes.length - 1
            '                appendText xmlC1Nodes(j).Text
            '            Next
        End If
        'appendText xmlEntryNode.text
        'Set xmlThumbnailNodes = xmlEntryNode.selectNodes("/media:group/media:thumbnail")
        'Trace "Thumbnail = ", xmlThumbnailNodes.Length
    Next

    Exit Sub

ErrorHandler:
    appendText "Error in ParseSearchresult ", Err.Description, Erl

End Sub

[coolcurrent4u]

@Doogle thanks, how can i give a rating!

[Doogle]

There's a little 'star' icon next to the 'report post' icon on the bottom left hand side of the Post, on the same line as 'Reply' and 'Reply With Quote'

It was much more obvious before the changes

[coolcurrent4u]

thanks very much, i have been doing this 3 days

[MarkT]

I know it is settled but this is the method I would have used

Private Sub Command1_MouseDown(Button As Integer, Shift As Integer, X As Single, Y As Single)
Dim objDoc As MSXML2.DOMDocument
Dim objNodeList As IXMLDOMNodeList
Dim objEntryNode As IXMLDOMNode
Dim objUrlAttrib As IXMLDOMAttribute
Dim objMediaNode As IXMLDOMNode

    Set objDoc = New MSXML2.DOMDocument
    objDoc.loadXML GetXML ' <-- Load however you need to

    ' load all the entry nodes
    Set objNodeList = objDoc.selectNodes("//entry")

    For Each objEntryNode In objNodeList
        ' display the title of the current entry node
        Debug.Print objEntryNode.selectSingleNode("title").Text

        ' display the first thumbnail url
        Set objMediaNode = objEntryNode.selectSingleNode("media:group/media:thumbnail")
        Set objUrlAttrib = objMediaNode.Attributes.getNamedItem("url")

        Debug.Print vbTab & objUrlAttrib.Text
    Next

    Set objDoc = Nothing
End Sub

Private Function GetXML() As String
Dim strXML(24) As String

    strXML(0) = "<?xml version='1.0' encoding='UTF-8'?>"
    strXML(1) = "<feed xmlns='http://www.w3.org/2005/Atom' xmlns:media='http://search.yahoo.com/mrss/'>"
    strXML(2) = "<entry>"
    strXML(3) = "<title>Progression! 9 more pounds to goo!</title>"
    strXML(4) = "<media:group>"
    strXML(5) = "<media:thumbnail url='http://i.ytimg.com/vi/7MTjYXt3rLQ/default.jpg'/>"
    strXML(6) = "<media:thumbnail url='http://i.ytimg.com/vi/7MTjYXt3rLQ/mqdefault.jpg'/>"
    strXML(7) = "<media:thumbnail url='http://i.ytimg.com/vi/7MTjYXt3rLQ/hqdefault.jpg'/>"
    strXML(8) = "<media:thumbnail url='http://i.ytimg.com/vi/7MTjYXt3rLQ/1.jpg'/>"
    strXML(9) = "<media:thumbnail url='http://i.ytimg.com/vi/7MTjYXt3rLQ/2.jpg'/>"
    strXML(10) = "<media:thumbnail url='http://i.ytimg.com/vi/7MTjYXt3rLQ/3.jpg'/>"
    strXML(11) = "</media:group>"
    strXML(12) = "</entry>"
    strXML(13) = "<entry>"
    strXML(14) = "<title>Plank Variations Workout with Max Wettstein</title>"
    strXML(15) = "<media:group>"
    strXML(16) = "<media:thumbnail url='http://i.ytimg.com/vi/O1Nd8lZFGpc/default.jpg'/>"
    strXML(17) = "<media:thumbnail url='http://i.ytimg.com/vi/O1Nd8lZFGpc/mqdefault.jpg'/>"
    strXML(18) = "<media:thumbnail url='http://i.ytimg.com/vi/O1Nd8lZFGpc/hqdefault.jpg'/>"
    strXML(19) = "<media:thumbnail url='http://i.ytimg.com/vi/O1Nd8lZFGpc/1.jpg'/>"
    strXML(20) = "<media:thumbnail url='http://i.ytimg.com/vi/O1Nd8lZFGpc/2.jpg'/>"
    strXML(21) = "<media:thumbnail url='http://i.ytimg.com/vi/O1Nd8lZFGpc/3.jpg'/>"
    strXML(22) = "</media:group>"
    strXML(23) = "</entry>"
    strXML(24) = "</feed>"

    GetXML = Join(strXML, vbCrLf)
End Function

[coolcurrent4u]

thanks for this. i tested and it worked! so no need for all the namespace reference?
